JMR Tube Die

  • Sale
  • Regular price $150.00
Shipping calculated at checkout.

These dies fit all JMR Benders and can be used to bend the specified size in mild steel, stainless steel, DOM, Docal, 4130 chrome moly and more.

Material Size – refers to actual Outside Diameter of the tube as measured with a caliper.
CLR – stands for Center Line Radius, meaning the bend radius as measured from the center rotation point of the die to the middle of the tubing. (see image)
Minimum Wall – denotes the minimum recommended wall thickness for consistent high quality wrinkle free bends at the specified radius in mild steel. Please call for recommendations with aluminum, stainless etc.
Max Degree of Bend – Dies can be purchased to bend up to 90 degrees or up to a full U-bend of 180 degrees after springback
